Pharmaceutical vacuum freeze dryer

Product overview

Pharmaceutical vacuum freeze dryer is one of the mainstream pharmaceutical equipment on the market. It uses vacuum freezing technology to effectively reduce the moisture content of drugs and ensure the quality and stability of drugs. Our pharmaceutical vacuum freeze dryer has the advantages of high efficiency, energy saving, easy operation and convenient maintenance. It is one of the indispensable equipment for pharmaceutical companies.

The pharmaceutical vacuum freeze dryer uses vacuum and low-temperature freezing technology to freeze and drain the water or other solvents in the solution or suspension to obtain a dry solid product. This drying method is widely used in the pharmaceutical field, and can be used in pharmaceutical fields such as biological products, chemical products, bottle freezes (lyophilized injections), plate freezes (raw materials), natural drugs, heat-sensitive drugs, antibiotics, oral freeze-dried tablets, etc. A summary of refrigeration system failure problems of pharmaceutical vacuum freeze dryers includes high-pressure alarms, compressor motor overload, compressor thermal protection, and low oil level when the compressor is running. The advantages of freeze-drying technology include that drugs are dried under low-temperature vacuum conditions, so the decomposition rate is very low and the purity is high; freeze-dried products basically maintain the volume of the original solution when frozen, and are loose and porous, with beautiful appearance and uniform color.

Product advantages

1. High efficiency and energy saving: Using advanced vacuum freezing technology, it can effectively reduce the moisture content of drugs and ensure the quality and stability of drugs. At the same time, the equipment has low energy consumption and saves more than 30% energy than traditional drying equipment.

2. Easy to operate: The equipment adopts automatic control and is easy to operate. Only simple operating steps are needed to complete the drying process of medicines.

3. Easy maintenance: The maintenance of the equipment is simple, and only some wearing parts need to be replaced regularly to ensure the normal operation of the equipment.

4. It has a fully automatic heating function for the shelves, monitors the temperature at any time, and has a temperature control function.

4. Siemens PLC programmable control system, one-button fully automatic control, safe and stable;

5. Imported temperature control: using PID adjustment for precise temperature control;

6. The human-machine interface adopts a 7-inch standard LCD touch screen, which is simple and convenient to operate.

7. Humanized design operation interface allows you to follow the freeze-drying progress of items anytime and anywhere;

8. Equipped with host computer communication interface (supports remote monitoring function);

9. Control system: equipped with automatic and manual systems, which are safe, reliable, convenient and practical

10. The voltages are: 380V and 220V.

11. Refrigeration unit: It adopts a compressor unit imported from Germany, which is safe, reliable and has stable performance.

12. Vacuum pump: Use a well-known brand vacuum pump with high pumping speed, low noise and strong filtration performance.

13. Automatically collect freeze-drying data, which can be viewed and downloaded;

14. Defrost system: non-electric heating defrost method, high safety performance and fast defrost speed;

15. Quality assurance: Our pharmaceutical vacuum freeze dryer uses high-quality materials and advanced technology to ensure the quality and performance of the equipment. At the same time, we also provide one-year free warranty service so that you have no worries. Service guarantee: Our sales team will provide personalized equipment selection and solution design services according to your needs. Our after-sales service team will also provide a full range of technical support and maintenance services during the operation of the equipment to ensure the normal operation of the equipment. If you have any questions or needs about our products, please feel free to contact us and we will provide you with satisfactory service as soon as possible.

Application areas

The application fields of pharmaceutical vacuum freeze dryers mainly include freeze-drying of Western medicines and traditional Chinese medicines, as well as applications in biological products, such as active vaccines or blood products. It can also be used to prepare products such as drugs, biologics, and medical devices to maintain their activity and stability.

Technical parameters

1. Freezing temperature: Generally below -50℃, the lowest can reach -80℃.

2. Drying temperature: generally below 40℃, up to 60℃.

3. Freezer volume: Generally between 100L and 1000L, select according to needs.

4. Drying chamber volume: Generally between 50L and 500L, select according to needs.

5. Vacuum degree: generally between 10Pa and 1Pa, adjustable.

6. Driving mode: Generally driven by a compressor, it can also be driven by a heat pump.

7. Power supply: Generally, a three-phase AC power supply is used, with a voltage between 380V and 415V.

8. Freeze drying time: generally between 8 and 24 hours, depending on the material properties and processing volume.

9. Operation mode: Generally, automatic control is used, but manual control is also available.

10. Equipment size: It varies according to the equipment model and specifications, generally between 1000mm×800mm×1500mm to 2000mm×1500mm×2000mm.

We will briefly introduce the product introduction of pharmaceutical vacuum freeze dryers here. If you need to customize and purchase a pharmaceutical vacuum freeze dryer, please contact us, or go directly to the factory to inspect the specific situation!

The pharmaceutical vacuum freeze dryer uses vacuum and low-temperature freezing technology to freeze and drain the water or other solvents in the solution or suspension to obtain a dry solid product.

The application fields of pharmaceutical vacuum freeze dryers mainly include freeze-drying of Western medicines and traditional Chinese medicines, as well as applications in biological products, such as active vaccines or blood products. It can also be used to prepare products such as drugs, biologics, and medical devices to maintain their activity and stability.

1. Freezing temperature: Generally below -50℃, the lowest can reach -80℃.

2. Drying temperature: generally below 40℃, up to 60℃.

3. Freezer volume: Generally between 100L and 1000L, select according to needs.

4. Drying chamber volume: Generally between 50L and 500L, select according to needs.

5. Vacuum degree: generally between 10Pa and 1Pa, adjustable.

6. Driving mode: Generally driven by a compressor, it can also be driven by a heat pump.

7. Power supply: Generally, a three-phase AC power supply is used, with a voltage between 380V and 415V.

8. Freeze drying time: generally between 8 and 24 hours, depending on the material properties and processing volume.

9. Operation mode: Generally, automatic control is used, but manual control is also available.

10. Equipment size: It varies according to the equipment model and specifications, generally between 1000mm×800mm×1500mm to 2000mm×1500mm×2000mm.
